Small riding card
Product Name:Small riding card, also known as: riding type card, square steel elevator.
Scope of application:For square steel pipe 30mm x 30mm x 2.0mm.
Generally, the specification of galvanized square steel pipe on the market is 30mm × 30mm × 1.7mm.
Material:Hot-rolled steel plates.
Role:It shall be used with M10 screw rod, small riding card M10, bolt and matching, and hang galvanized square steel pipe.
Installation spacing:10-15 times spacing of riser pipe diameter. Specific according to the design requirements or construction requirements of the spacing installation.
The distance between the small riding card and the mounting piece is generally 1 meter, which is installed according to the design requirements or the spacing specified in the construction requirements.
Note:
- The finished product in stock is cold galvanized. If hot dip galvanizing is required, temporary customization is required.
- The size of square steel pipe used shall not exceed 30.5mm.
- If it is difficult to insert individual vacancies, insert them in another direction.
