Suspension pipe clip
Product Name:Suspension pipe clip, also known as: horizontal pipe clip, horizontal pipe clip.
Scope of application:For square steel pipe 30mm x 30mm x 2.0mm. Generally, the specification of galvanized square steel pipe on the market is 30mm × 30mm × 1.7mm.
Material:Hot-rolled steel plates.
Role:Hanging HDPE pipe or supporting anchor stop short pipe on horizontal pipe.
Installation spacing:10 times spacing of riser pipe diameter.
| Pipe Specification | 50mm | 63mm | 75mm | 90mm | 110mm | 125mm | 160mm | 200mm | 250mm | 315mm |
| Installation spacing | 0.5mm | 0.63mm | 0.75mm | 0.9mm | 1.1mm | 1.25mm | 1.6mm | 2.0mm | 2.5mm | 3.15mm |
Specific according to the design requirements or construction requirements of the spacing installation.
Note:
- The finished product in stock is cold galvanized. If hot dip galvanizing is required, temporary customization is required.
- The size of square steel pipe used shall not exceed 30.5mm.
- If it is difficult to insert individual vacancies, insert them in another direction.
